The MC10G Fiber Optic Media Converter is designed to operate in a high-temperature NEMA environment with 1* 100/1000/10000M TX copper port and 1* 1000/10000M SFP Fiber Optic Port. It is primarily intended for large, higher speed/bandwidth-demanding workgroups that require expansion of the Ethernet network. It can extend the 1GB, 2.5GB, 5GB and 10GB TX Ethernet up to 20Km distances via the SFP 10 Gigabit Ethernet Fiber-optic module. It is a high-performance, cost-effective, and flexible solution for a wide range of applications in the 5G communication network or LAN campus networks.
The MC10G offers an easy-to-use and configuration facility, via the WEB interface, it can be programmed for basic management functions such as per port speed duplex settings, Port Trunking, VLAN, Port Mirroring, network security authentication and misc. configurations. Additionally, the firmware includes advanced features such as IGMP snooping, QoS (Quality of Service), broadcast storm and bandwidth control, to enhance bandwidth utilization. The extended temperature capability for meeting NEMA specifications satisfies very critical applications requiring high quality data transmission performance with high reliability.
Applications include Telecom 5G Networks, ITS Intelligent Traffic System, Metro Operation, HDTV Broadcasting System, IP cameras Surveillance, Homeland Security, Utility Management, Premise Networks, Military Hardened applications or anything requiring high speed Ethernet Network performance.

• 1* 1000/10000 Mbps SFP Port
• 1* 100/1000/10000 Mbps TX RJ45 Port
• Automatic MAC address learning and aging
• Automatically support IGMP (Multicasting)
• 100/1000/10000 Mbps Auto-negotiation, auto-MDI-MDI-X
• Transmission Distance Up to 20 Km with Single Mode SFP Module (Included)
• LED indicators for monitoring power/link/activity
• Supports 1100/1000/10000 Mbps-Full/Half-duplex
• Supports Daisy-Chain connection
• Supports Broadcast Storm Control
• NEMA operating temperature range
