Vi-Link HD SDI Video Equipment: The DL1800T is a fiber optic digital multiplexer that transmits up to 18 channels of high-quality uncompressed digital 3G HD SDI video signals over one single-mode cable. It is a cost-effective selection for transporting high-quality SDI camera pictures from a remote location to the operation center via a long fiber optic cable.
The DL1800T is compatible with all SMPTE rates: SMPTE259M SDI from 143 to 360 Mbps, SMPTE344M 540Mbps, SMPTE292M HD-SDI 1.485 Gbps, SMPTE372M Dual Link HD-SDI 2,97 Gbps, SMPTE424M Dual Speed 3G-SDI 2.97 Gbps.
The DL1800T offers a fully serial digital video encoding/decoding of real time high quality digital video providing adjustment free operation over a wide operational range. Using CWDM technologies for distances from back-to-back to 20 Kilometers, our digital signaling offers superior receiver output stability, which is unaffected by changes in fiber path attenuation due to aging or splicing points.
The extended temperature capability of the DL1800T satisfies very critical applications requiring high quality video performance with high reliability.
Applications include Broadcast Video Production, Video Editing, Unmanned Aircraft Vehicle Days & Nights Monitoring Systems, ITS Intelligent Traffic System, Metro & Railroad Monitoring System, Homeland Security, Utility Management, Premise Networks, Military Hardened applications or anything requiring HD quality video performance.

18 Channels High Quality Digital Broadcast Video Transmitter
Single Mode Fiber with CWDM Technology
Real Time High 3G-HD-SDI Video
Compatible with all SMPTE3G SDI Rates
– SMPTE259M SDI from 143 to 360 Mbps, SMPTE344M 540Mbps,
– SMPTE292M HD-SDI 1.485 Gbps, SMPTE372M
– Dual Link HD-SDI 2,97 Gbps,
– SMPTE424M Dual Speed 3G-SDI 2.97 Gbps
AGC Single mode Transmission of 0 to 20 Km
ST Connector
90~240 VAC or +24 VDC, +28 VDC, -48 VDC
NEMA Temperature
