Vi-Link HM10TR Mini 4K HDMI optical Transmitter and receiver pair is designed to send 1 channel of 1.4a compliant HDMI Video with embedded audio over one fiber. It can operate over dual/single fiber in DVI mode when HDCP compliance is not required.

The 4K HDMI optical transceiver supports the transmission of an uncompressed lossless HDMI 1.4a signal over 1310nm single mode fiber at a resolution of 4Kx2K. Transmitter converts an HDMI signal to a single 10Gb/s serial data stream for transmission over dual/single fiber. Receiver converts the serial data back to an HDMI signal.

These small modules utilize one fiber with a standard locking LC optical connector. This product is ideal for large screen displays, conferencing systems and home entertainment.

4K x 2K 3D HDMI Video Resolution
10 Gigabits Serial Data Transmission
Compliance HDCP and HDMI 1.4a
Support DDC, CEC, HPD
No Settings or Adjustments
Automatic recognizes HDCP, EDID, CEC
Transmission Up To 2Km @ 1310nm MM, 10 Km @1310nm SM Fiber
Standard LC Connector
Integrated USB connector for Power
Dual Supply via HDMI Port & USB port
