The Vi-Link IE12 is a Unmanaged Industrial Fast Ethernet Switch. It provides one 1000Mbps fiber optic SFP LC port and two 10/100/1000Mbps electrical RJ45 ports. The IE12 is designed to meet the various industrial application needs and provide a wide range of industrial Ethernet network communication solutions, including linking multiple remote traffic intersections to the Traffic Operation Center. The IE12 supports DIN rail and panel mounting for installation in the industrial environment.
Applications include ITS Intelligent Traffic Control System, Homeland Security, Metro & Railroad Systems, Oil & Gas Monitoring System, Utility Management, Premise Networks, Military Hardened applications or anything requiring high quality Data Transmission performance.

• 1 1000Mbps SFP
• 2 Ports 10/100/1000Mbps RJ45
• Automatic MAC address learning and aging
• Automatically support IGMP (Multicasting)
• 10/100/1000Mbps Auto-negotiation, auto-MDI-MDI-X
• Transmission Distance Up to 50 Km with Single Mode Fiber
• LED indicators for monitoring power/link/activity
• Supports 10/100/1000Mbps-Full/Half-duplex
• Supports Wall-mount and DIN-Rail installation
• Supports Daisy-Chain connection
• Supports Broadcast Storm Control
• Super lightening protection, IP40 protection.
• Excellent heat elimination without cooling fan.
• Redundant dual 10~57 VDC power inputs.
• NEMA operating temperature range.
