Vi-Link IE480 is an Industrial Ethernet network layer 3 switch designed for robust performance across various layers of network architecture with 8* 10/100/1000M TX downlink ports, 4* 1/10G SFP+ uplink ports, and a console port, it is engineered for seamless, high-speed connectivity.
In the role of a core layer switch, the Vi-Link IE480 functions as the backbone of a network, handling substantial data traffic with its high-capacity uplink ports. Its 1/10G SFP+ uplink ports ensure high-speed data transfer and reduce latency, making it ideal for critical enterprise applications. The IE480 effectively manages data flows between the core and access layers. It supports essential protocols like SNMP, IEEE 802.1, STP, and RSTP, ensuring seamless distribution and high availability of network services. The DoS attack defense feature enhances security, making the network robust against malicious activities. In the access layer, the IE480’s adaptive Ethernet ports provide flexible connectivity options for end devices. Automatic adaptation to full duplex or half-duplex modes means it can efficiently manage varying device requirements and traffic loads. This makes it suitable for deployment in different business environments, from small offices to large enterprises.
8* 10/100/1000Base-T Ethernet ports
4* 1G/10G SFP+ ports
Layer 3 Model support OSPFv2, RIPv2, Static Route
Support both IPv4/IPv6 applications
LLDP, LLDP-MED protocol suitable for IIoT Applications
Port-based VLAN, IEEE 802.1Q VLAN, and GVRP to ease network planning
Support IEEE802.3az energy efficient Ethernet technology, 8K MAC address table
NEMA Temperature Compliance
1* 20 Km @ Fiber Optic Single Mode 10GB SFP included
Electric 8KV surge protection
Power input polarity protection design, no worry about wrong operation
Aluminum case, no fan design, IP40 rating
DIN Rail/Wall mounting
