IL160-13-15-1

$7,495.00

16 Channels Fiber Optic Mode Converter/Repeater 1310nm MM/SM SFP to SM ST composite fiber, up to 3 GB per protocol independent channel, dual single mode, transmission speed can be up to 40 Km, support NEMA Temperature, 90~240 VAC

Vi-Link Optical Mux equipment: The IL160 is a fiber optic 160GB CWDM transporter designed to transmit up to 16 independent channels in real-time digital signals transmission. This unique multiplexer is a cost-effective fiber expansion solution, without installing new fibers, the user can maximize fiber capacity up to 16 times with data that can be transferred up to 10 GB of digital data per channel to a new location. The extended distance between locations is up to 80 km, however, it can be used for longer distance with its optical repeater function.
The IL160 can accept all digital signals between 1 GB to 10 GB from various communication devices through its SFP input and output ports such as 1/10GB Ethernet, HD SDI 3/6G Video, 2/4/8K HDMI video short range 1/10G MM fiber link, SONET, SDH, FDDI, ESCON and so on. Protocol independent ports enable users to re-configure an entire network without re-configuring the IL160. For example, a 10GB Copper Ethernet I/O connection can be changed to a MM Optic 10GB Ethernet simply by disconnecting the Copper Ethernet SFP from the IL160 and connect the MM Optic Ethernet to the IL160.
The extended temperature capability of the IL400 satisfies very critical applications requiring high quality video performance with high reliability.

Applications include High Speed Ethernet Networks, Large Data Center, Broadcasting Video productions, High Speed Leased Fiber, 5G Telco, S Telco feeder, SCADA, SONET OC-1, OC-3, OC-12, OC-48, SDH STM-1, STM-4, STM16, DS3, E3, CEPT-1, FDDI, ESCON, HD-SDI, HDMI Video and many other standard or proprietary digital optical signals.

Multiplex 16 Full Duplex Optical Channels
LAN/WAN, SAN High Speed Signals
Individual Channel Bandwidth From 1.25 Gbps to 10 Gbps
Transmit Synchronous and Asynchronous Data Up to 40 Km
100% Protocol Independent I/O
Plug and Play
No Bandwidth Penalty
1 RU Rack Mountable
NEMA Temperature
