The MC10 Unmanaged Media Converter series is designed to operate in high-temperature NEMA environment with 1 x 10/100/1000Mbps copper port 1 and 1 x 1000 Base-SX Fiber Optic Ethernet Port. The converter mediates between a 10/100/1000M Base-TX segment and a 1000Base-SX segment. It is primarily designed for large, higher speed/bandwidth-demanding workgroups that require expansion of the Ethernet network. It can extend the conventional 10M Ethernet, 100M Fast Ethernet or 1000M Ethernet to 20Km~100Km via the Gigabit Ethernet Fiber-optical Line. It is high-performance, cost effective and flexible solutions for a wide range of applications in the field of LAN campus network.
With the Web-based management MC1600 chassis, the MC10 will offer an easy-to-use and configuration facility, via the WEB interface, it can be programmed for basic management functions such as per port speed duplex settings, Port Trunking, VLAN, Port Mirroring, network security authentication and misc. configurations. Additionally, the firmware includes advanced features such as IGMP snooping, QoS (Quality of Service), broadcast storm and bandwidth control, to enhance bandwidth utilization. The extended temperature capability for meeting NEMA specifications satisfies very critical applications requiring high quality data transmission performance with high reliability.
Applications include ITS Intelligent Traffic System, Metro Operation, HDTV Broadcasting System, IP cameras Surveillance, Homeland Security, Utility Management, Premise Networks, Military Hardened applications or anything requiring high speed Ethernet Network performance.

• 1 1000Mbps SFP
• 1 Port 10/100/1000Mbps RJ45
• Automatic MAC address learning and aging
• Automatically support IGMP (Multicasting)
• 10/100/1000Mbps Auto-negotiation , auto-MDI-MDI-X
• Transmission Distance Up to 50 Km with Single Mode Fiber
• LED indicators for monitoring power/link/activity
• Supports 10/100/1000Mbps-Full/Half-duplex
• Supports Wall-mount and DIN-Rail installation
• Supports Daisy-Chain connection
• Supports Broadcast Storm Control
• NEMA operating temperature range
