Vi-Link MD32 Copper Data Small Form Pluggable (SFP) Transceiver

The Vi-Link MD32 Copper Data SFP Transceiver is a high-performance, cost-effective module designed for reliable serial communication. Fully compliant with the EIA RS-232 interface, this transceiver supports data rates from DC to 112 Kbps and transmission distances of up to 100 meters over unshielded twisted-pair (UTP) Category cable.

The MD32 module is compatible with most Vi-Link Optical Mode Converters and Mode Multiplexers, allowing seamless extension of bi-directional RS-232 data between a remote site and a control center—without the need for additional equipment or fiber infrastructure.

Support EIA RS-232
Asynchronous Data Speed Up To 112 Kbps
Hot-pluggable SFP footprint
RoHS compliant and lead-free
Single +3.3V power supply
Extended case temperature range (-40°C to +85°C)
Fully metallic enclosure for low EMI
Compact RJ-48 connector assembly
RJ45 Connector
