The IE10G Industrial Fiber Optic Media Converter is designed to operate in a high-temperature NEMA environment with 1 x 10 Gb TX copper port and 1 x 1G/2.5G/5G/10G SFP Fiber Optic Port. It is primarily intended for large, higher speed/bandwidth-demanding workgroups that require expansion of the Ethernet network. It can extend the 10G TX Ethernet up to 20Km distances via the SFP 10 Gigabit Ethernet Fiber-optic SM module. It is a high-performance, cost-effective, and flexible solution for a wide range of applications in the 5G communication network or LAN campus networks.
The IE10G offers an easy-to-use and configuration facility, via the WEB interface, it can be programmed for basic management functions such as per port speed duplex settings, Port Trunking, VLAN, Port Mirroring, network security authentication and misc. configurations. Additionally, the firmware includes advanced features such as IGMP snooping, QoS (Quality of Service), broadcast storm and bandwidth control, to enhance bandwidth utilization. The extended temperature capability for meeting NEMA specifications satisfies very critical applications requiring high quality data transmission performance with high reliability.
Applications include Telecom 5G Networks, ITS Intelligent Traffic System, Metro Operation, HDTV Broadcasting System, IP cameras Surveillance, Homeland Security, Utility Management, Premise Networks, Military Hardened applications or anything requiring high speed Ethernet Network performance.

Complies with IEEE 802.3an 10G Base-T, IEEE 802.3ae 10G Base-SR, LR, ER, ZR
1 x 1G/2.5G/5G/10G Fiber Optic SFP Module
1 x 10G TX Copper RJ45
20 Km @ Fiber Optic Single Mode (Swappable for other distance requirement)
Support Jumbo frame supports Transport, Diagnostics, Monitoring and Network Performance Measuring
Supports IEEE 802.1Q VLAN Tagging and Stacking, QoS Level Traffic Shaping and Policing
E-Line, E-LAN and E-Access Supports
NEMA Temperature Compliance
DIN Rail Mount
