Vi-Link ME336 is an Industrial High Power PoE++ Splitter that can split the 48-56V DC over the existing Ethernet cable into the 3.3-36VDC adjustable power output via an adjustable button. With an LED display on the front panel, it can show the output voltage and current in real-time. It supports passive 10/100/1000Mbps Ethernet connection ability and complies with IEEE 802.3bt High Power over Ethernet standard that supports up to 70-watt output power to powered devices. The ME336 is designed to work under the operating temperature range from -40 to 80 degrees C to fulfill the growing industrial applications. The ME336 is an ideal solution for transferring power directly to traditional network devices with high power demand without installing additional power outlets and electrical cabling in the industrial environment.
‘The data transmission, up to Gigabit speeds, with power output voltages of 3.3-36VDC, run simultaneously up to the Ethernet limit of 100 meters. With a simple Ethernet cable connected to your PoE+ Switch or injector, this Splitter can give up to 70W (36VDC) to a non-PoE device in tough or industrial environments via your choice
of output — a terminal block — and still provide a gigabit network connection. It’s a great choice for non-PoE cameras, laptops, and other devices that require a power adapter, and it’s cheaper in both time and money than hiring an electrician.
Applications include Telecom 5G Networks, ITS Intelligent Traffic System, Metro Operation, HDTV Broadcasting System, IP cameras Surveillance, Homeland Security, Utility Management, Premise Networks, Military Hardened applications or anything requiring high speed Ethernet Network performance.

Splits an IEEE 802.3bt PoE++ connection into power and Gigabit Ethernet for non-PoE devices
LED Display showing output voltage and current
3.3-36 VDC output with power up to 36V / 1.94A / 70W via terminal block
Adjustable Button to adjust 3.3-36VDC based on demands
Up to 100 Meters
RJ45 input port up to 90W from an IEEE 802.3bt
Compliant PoE injector or PoE switch (PSE)
Short-circuit, overload and high-voltage protection, ESD protection up to 8 kV
(air) and 6 kV (contact), Port surge protection up to 2 kV
NEMA Temperature Compliance
DIN Rail Mount
