The VO-BiDi-125 SFP transceivers are high-performance, cost-effective one-fiber bi-directional transmission (BiDi) modules supporting a dual data rate of 1.25Gbps and 40km transmission distance with SMF.

The transceiver consists of four sections: an FP laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA), the MCU control unit and the 1310/1550nm WDM coupler. The transceiver is using one SM fiber for transmitting and receiving data information at the same time.. All modules satisfy class I laser safety requirements.

The VO-BiDi-125 transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.

Dual data-rate of 1.25Gbps operation
1310nm FP laser and 1550nm PIN photodetector for 40km transmission
Compatible with SONET OC-24-LR-1
Compliant with SFP MSA and SFF-8472 with duplex LC receptacle
Digital Diagnostic Monitoring: Internal Calibration or External Calibration
Compatible with RoHS
+3.3V single power supply
Operating case temperature:
