Vi-Link HD SDI equipment: The DL130 is a fiber optic digital Transmitter/multiplexer for transmitting 3G HD SDI broadcast video signal and Stereo Audio data over a single-mode fiber optic cable. It is a cost-effective selection for transporting and controlling broadcasting quality video images.
The DL130 is compatible with all SMPTE rates: SMPTE259M SDI from 143 to 360 Mbps, SMPTE344M 540Mbps, SMPTE292M HD-SDI 1.485 Gbps, SMPTE372M Dual Link HD-SDI 2,97 Gbps, SMPTE424M Dual Speed 3G-SDI 2.97 Gbps serial digital signal over long distance single mode fiber optic cable. It is also capable of transmitting 600 Ohms stereo audio up to 20 Khz.
The DL130 offers a fully serial digital video encoding/decoding of uncompressed real time video providing adjustment free operation over a wide operational range. Using AGC and CWDM technologies for distances from back-to-back to 50 Kilometers, our digital signaling offers superior receiver output stability, which is unaffected by changes in fiber path attenuation due to aging or splicing points.
The extended temperature capability of the DL130 satisfies very critical applications requiring high quality video performance with high reliability. It is the direct replacement equipment for upgrading old analog video monitoring network to the high-quality HD video monitoring system.
Applications include ITS Intelligent Traffic System, Metro & Railroad systems, Avionic Surveillance, Oil and Gas Systems, Homeland Security, Utility Management, Premise Networks, Military Hardened applications or anything requiring HD quality video performance.

Digital Broadcast Video Transmission
Uncompressed Stereo Audio
Single Mode Fiber With CWDM Technology
Real Time High Quality 3G-HD-SDI Video
Compatible with all SMPTE3G SDI Rates
– SMPTE259M SDI from 143 to 360 Mbps,
SMPTE344M 540Mbps,
– SMPTE292M HD-SDI 1.485 Gbps, SMPTE372M
Dual Link HD-SDI 2,97 Gbps,
– SMPTE424M Dual Speed 3G-SDI 2.97 Gbps
600 Ohms Audio Input/Output
+12 VDC or 90~240 VAC (Rack card)
NEMA Temperature
