VI-LINK Single Channel HD SDI Video equipment: The VI-LINK DL1SB is a fiber optic digital Transmitter designed to be used with DL1800 in the Daisy-Chan Configuration for transmitting 1 high-quality 3G HD SDI digital video channel with video pathological code over a single mode fiber optic cable. It is a cost-effective selection for transporting broadcast-quality video images from multiple locations (up to 18 locations).
The DL1SB is compatible with all SMPTE rates: SMPTE259M SDI from 143 to 360 Mbps, SMPTE344M 540Mbps, SMPTE292M HD-SDI 1.485 Gbps, SMPTE372M Dual Link HD-SDI 2,97 Gbps, SMPTE424M Dual Speed 3G-SDI 2.97 Gbps serial digital signal over long distance single mode fiber optic cable.
The DL1SB offers a fully serial digital video encoding/decoding of uncompressed real time video providing adjustment free operation over a wide operational range. Using AGC technology for distances from back-to-back to 50 Kilometers, our digital signaling offers superior receiver output stability, which is unaffected by changes in fiber path attenuation due to aging or splicing points. The extended temperature capability of the DL1SB satisfies very critical applications requiring high quality video performance with high reliability. It is the direct replacement equipment for upgrading old analog video monitoring network to the high-quality HD video monitoring system.
Applications include ITS Intelligent Traffic System, Metro & Railroad systems, Avionic Surveillance, Oil and Gas Systems, Homeland Security, Utility Management, Premise Networks, Military Hardened applications or anything requiring HD quality video performance.

Uncompressed Digital Video Transmission
Real Time High Quality Broadcast 3G-HD-SDI Video
Compatible with all SMPTE3G SDI Rates
– SMPTE259M SDI from 143 to 360 Mbps, SMPTE344M 540Mbps,
– SMPTE292M HD-SDI 1.485 Gbps,
– SMPTE372M Dual Link HD-SDI 2,97 Gbps,
– SMPTE424M Dual Speed 3G-SDI 2.97 Gbps
Fully Compliant with Video Pathological Code
Fiber Loop-Through for Daisy-Chain Configuration
Total Distance up to 50 Km
NEMA Temperature
