Vi-Link HD SDI equipment: The DL20T is a fiber optic digital Transmitter for transmitting high-quality broadcast video 3G HD SDI signal and 10/100/1000M Ethernet link over a single mode fiber optic cable.
The DL20T is compatible with all SMPTE rates: SMPTE259M SDI from 143 to 360 Mbps, SMPTE344M 540Mbps, SMPTE292M HD-SDI 1.485 Gbps, SMPTE372M Dual Link HD-SDI 2,97 Gbps, SMPTE424M Dual Speed 3G-SDI 2.97 Gbps. The 10/100/1000M Ethernet channel supports store and data forwarding with extremely low latency. It is high-performance, cost effective and flexible solutions for a wide range of applications in the field of LAN campus network.
The DL20T offers a fully serial digital video encoding/decoding of real time high quality digital video providing adjustment free operation over a wide operational range. Using automatic gain control and state-of-the-art multiplexing, combining with CWDM technologies for distances from back-to-back to 50 Kilometers, our digital signaling offers superior receiver output stability, which is unaffected by changes in fiber path attenuation due to aging or splicing points. The extended temperature capability of the DL20T satisfies very critical applications requiring high quality video performance with high reliability.
Applications include Broadcast Video Production, Video Editing, Unmanned Aircraft Vehicle Days & Nights Monitoring Systems, ITS Intelligent Traffic System, Metro & Railroad Monitoring System, Homeland Security, Utility Management, Premise Networks, Military Hardened applications or anything requiring HD quality video performance.

Digital Broadcast Video Transmitter
10/100/1000M Ethernet Link
Single Mode Fiber with CWDM Technology
Real Time High Quality 3G-HD-SDI Video
Compatible with all SMPTE3G SDI Rates
– SMPTE259M SDI from 143 to 360 Mbps, SMPTE344M 540Mbps,
– SMPTE292M HD-SDI 1.485 Gbps, SMPTE372M, SMPTE424M
– Dual Link HD-SDI 2,97 Gbps, Dual Speed 3G-SDI 2.97 Gbps
Fully Compliant with IEEE802.3, IEEE802.3u, IEEE802.3ab standard
Auto-detection of half/full duplex transfer mode
Auto-negotiation of 10/100/1000 Mbps rate and Auto-MDI/MDIX TX port
+5 VDC Power Adaptor
NEMA Temperature
