The HM12T is a fiber optic HDMI Video Transmitter with Bi-directional RS-232 data, it is designed to transmit 1 channel 4Kx2K 3D HDMI video, and 1 channel bi-directional RS232 data over one fiber optic cable. This is an uncompressed 10 Gigabits data stream transmission with no delay and high-quality HDMI 1.4 for up to 40 Km with single-mode fiber.

The extended temperature capability of the HM12T satisfies critical applications requiring high-quality video performance with high reliability. Applications include ITS Intelligent Traffic System, Metro & Railroad systems, Avionic Surveillance, Oil and Gas Systems, Homeland Security, Utility Management, Premise Networks, Military Hardened applications or anything requiring HD quality video performance.

4K x 2K 3D HDMI Video Over Fiber Extension
Single Mode Fiber (SFP)
10 Gigabit Data Stream Transmission
Up to 40 Kilometers @ 1310/1550nm SM
HDMI Output at 720P or 1080P
Support all Modes Up To 4K x 2K x 30
Compliance HDCP and HDMI 1.4a
Support DDC, CEC, HPD
IEEE – RS-232 Bi-Directional Data up to 9.6 Kbps
+ 5VDC Power Adapter
